| Authentication Method | Biometric | |
| Dust/ Water Resistance | IP65 | |
| Memory | Max Users | 10,000 |
| Fingerprints (Templates) | 20,000 (1:1) 3,000 (1:N) | |
| Logs | 100,000 | |
| Images | X | |
| Communication | With Server | TCP/IP |
| Other | USB | |
| Wireless LAN(Wi-Fi) | X | |
| Wiegand OUT | O | |
| RS232 | X | |
| RS485 | OSDP | |
| Wiegand IN | O | |
| Display | LCD | 1.77″Color LCD |
| Backlight | O | |
| Embedded Camera | X | |
| Card | 125khz-EM | O |
| HID Prox | X | |
| HID iclass | X | |
| 13.56MHz Smart Card | O | |
| Keypad | X | |
| Function keys | 4 | |
| Door Phone | X | |
| FP Sensor | Platen Area | 14.8 X 17.9 mm |
| Resolution | 500 dpi | |
| Dimension | (W) X (H) X (D) mm | 58 X 187.9 X 51.6 mm |
| FRR /FAR | 0.1% / 0.0001% | |
| Operating Temperature | -20 ~ 60℃ | |
Specification
