ProCapture-T is an access control terminal applying the most advanced Z-ID fingerprint sensor. Its outstanding performance provides a high identification rate towards dry, wet and rough fingers, being capable to detect alive finger for a higher security level. The fingerprint verification speed has been dramatically increased by its optimized fingerprint algorithm and the brand new ZMM220 hardware platform, equipped with a fast 1.2GHz processor.
- Fingerprint Capacity6,000
- Card Capacity10,000
- Transaction Capacity100,000
- User Photo Capacity3,000
- Event Photo Capacity7,000
- CommunicationTCP/IP / RS485 (For Slave Reader) / USB Host / Wiegand Input / Output / Security Relay Box
- Access Control InterfaceLock Relay Output / Alarm Output / Auxiliary Input / Exit Button / Door Sensor / Doorbell Output
- Hardware1.2GHz High Speed CPU / Memory 128MB RAM / 256MB Flash / Z-ID Fingerprint Sensor / 2.4 Inches TFT-LCD Screen / 125KHz EM Reader / IC Reader (Optional) / Hi-Fi Voice & Indicator / Tamper Switch Alarm / Touch Keypad / 120° Wide Angle Camera
- Standard FunctionAccess Levels / Groups / Holidays / DST / Bell Schedule / Duress Mode / Anti-Passback / Record Query / Custom Wallpaper & Screen Saver
- Special FunctionMultiple Verification Modes / Alive Finger Detection / Event Snapshot / User Photo (Optional) / ZK Encrypted Card (Optional) / Fingerprint Card
- CompatibilityWiegand Slave Reader / RS485 FP Slave Reader / ZKBioSecurity Software
- Operating Temperature-10°C ~ 50°C
- Dimension195.5 × 87 × 35 mm
- AlgorithmZKFinger V10.0
- FingerprintFAR≤0.0001%, FRR≤0.01%
- Operating Voltage12V DC
- Current Draw< 500mA
