Features
● This machine is used as the interface between the networking public address system and the fire center.● The forced interruption of the activation area is limited to the emergency area or extended to several adjacent areas,
● which shall be determined by the preprogramming of the networking mainframe.
● Each machine is able to control 16 areas and set up by means of the mainframe.
● In the same system, a number of machines are connected to the network so as to extend the area under control at will.
● The infrared remote controller is used to set up IP address.
| Number of channel | 16, extendable |
| Possibly activated adjacent area | Several, programmable |
| Logic level | +5~+24V/0V, settable |
| Protection | AC fuse×1 |
| Power supply | AC 220V/50-60Hz |
| Size of external packing (L×W×H mm) | 555×455×185 |
| Machine size (L×W×H mm) | 483×375×88 |
| Gross weight | 8.5kg |
| Net weight | 6.8kg |
